JEUX SF-816
Contact Agent
See Specification
JEUX SF-816
Post-Bed, Tape Laydown Machine with Fabric Edge Trimmer
JEUX SF-816 machine is equipped with fabric edge trimmer, which allows to precisely laydown tape exactly at the edge of the material, which enables to perform bottom hemming or overlapping seam later on.
Contact Agent
See Specification
Maximum Sealing Speed
9 m/min.
Maximum Temperature
800°C
Nozzle Unit
12 mm
Product overview

Machine for bonding tape laydown on material edge with hot air blow. This operation is required as a first step for seamless bottom hemming and two fabrics’ overlap joining. Thanks to in-built edge trimmer (similar to the one used with overlock) the laid-down tape is placed exactly at the very edge of the fabric, which then allows to either roll/hem the edge (using a dedicated binder) or to put on top the second fabric, achieving flat and stitchless seam.

Machine is equipped with differential feed (different speed of upper and lower roller), which allows to apply the tape even at curves or at difficult materials. Both the temperature and the speed of feeding and cutting are set on the easy-to-use color touch-screen panel. JEUX SF-816 body is designed to be able to install many types of tape binders or feeders on it. This technology can be used on both the synthetic and cotton materials.

KEY FEATURES
  • Differential Speed Top/Bottom Roller
  • Digital Tape Feeder (Tape Tension Control)
  • Adjustable Cutter Speed
  • Simple Binder for Hemming Included
  • Colour Touch Screen
  • Convertible Platform with Various Binders Possible to Install
See this machine in action

Bonding machines

JEUX SF-816

Post-Bed, Tape Laydown Machine with Fabric Edge Trimmer

JEUX SF-816 machine is equipped with fabric edge trimmer, which allows to precisely laydown tape exactly at the edge of the material, which enables to perform bottom hemming or overlapping seam later on.

Maximum Sealing Speed
9 m/min.
Maximum Temperature
800°C
Nozzle Unit
12 mm
Product overview

Machine for bonding tape laydown on material edge with hot air blow. This operation is required as a first step for seamless bottom hemming and two fabrics’ overlap joining. Thanks to in-built edge trimmer (similar to the one used with overlock) the laid-down tape is placed exactly at the very edge of the fabric, which then allows to either roll/hem the edge (using a dedicated binder) or to put on top the second fabric, achieving flat and stitchless seam.

Machine is equipped with differential feed (different speed of upper and lower roller), which allows to apply the tape even at curves or at difficult materials. Both the temperature and the speed of feeding and cutting are set on the easy-to-use color touch-screen panel. JEUX SF-816 body is designed to be able to install many types of tape binders or feeders on it. This technology can be used on both the synthetic and cotton materials.

KEY FEATURES
  • Differential Speed Top/Bottom Roller
  • Digital Tape Feeder (Tape Tension Control)
  • Adjustable Cutter Speed
  • Simple Binder for Hemming Included
  • Colour Touch Screen
  • Convertible Platform with Various Binders Possible to Install
Specification
All Functions
Specification
Arm Type
Post-Bed
Other
Fabric Edge Trimmer, Differential Top/Bottom Speed, Color Touch Screen
Max. Temperature
800°C
Max. Speed
10 m/min.
Standard Accessories
