LZ-2280N Series
High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
The cylinder bed zigzag stitch machine is best suited to the circular stitching processes of tubular products such as gridles, shorts and swimwear.
Contact Agent
See Series Specification (7)
Feeding amount
2.2-2.5
mm
Sewing speed
4000-5000
sti/min
Product overview
The sewing machine produces soft seams with consistency with a low tension applied to the thread even when it runs at a high speed.
Highly reliable models in the LZ-2280N series that respond to many different kinds of sewing specifications.
LZ-2282N High speed, 1-needle, Lockstitch, Standard Zigzag Stitching machine with Lower Knife.
LZ-2282N-7 High speed, 1-needle, Lockstitch, Standard Zigzag Stitching Machine with Lower Knife (with automatic thread trimmer)
LZ-2284C-7 High speed, Cylinder-bed, 1-needle, Lockstitch, Standard Zigzag Stitching Machine with Automatic Thread Trimmer (with standard 3-step zigzag stitching pattern changeover function)
LZ-2285N High speed, 1-needle, Lockstitch Fagoting Machines.
LZ-2282N / LZ-2282N-7
Productivity is dramatically increased
The machine incorporates a built-in lower knife that trims only the lower material. This allows the machine to simultaneously attach lace to the body of the foundation and trim only the body during processes to attach lace to the bottoms or tops of slips or to the joint seam lines of shorts.
The machine demonstrates consistent trimming performance
The knife is driven by a motor that runs independently from the sewing machine motor. With this feature, the knife can continue to run at a high speeds during trimming even when the speed of the machine is reduced during startup or when sewing curved sections. Furthermore, the knife is placed just beside the needle to provide a constant trimming width even on the curved sections.
The machine incorporates a built-in lower knife that trims only the lower material. This allows the machine to simultaneously attach lace to the body of the foundation and trim only the body during processes to attach lace to the bottoms or tops of slips or to the joint seam lines of shorts.
The machine demonstrates consistent trimming performance
The knife is driven by a motor that runs independently from the sewing machine motor. With this feature, the knife can continue to run at a high speeds during trimming even when the speed of the machine is reduced during startup or when sewing curved sections. Furthermore, the knife is placed just beside the needle to provide a constant trimming width even on the curved sections.
LZ-2284C-7
This is a cylinder-bed, lockstitch zigzag stitching machine based on the LZ-2284N-7 model. The cylinder-bed more than adequately facilitates the handling of tubular sewing products in circular sewing processes, thereby contributing to increased productivity and upgraded seam quality. This zigzag stitching machine is best suited to the attaching or counter stitching of elastic tape.
LZ-2285N
The pressure provided by the left- and right-hand sections of the fagoting holder can be separately adjusted in order to prevent an uneven material feed.
The sewing machine provided with an anti-material-slip function, which promises more beautifully finished seams, is included in three different model lineups.
LZ-2280NU High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine with Anti-material-slip type
LZ-2284NU High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
with Anti-material-slip type
(with standard/3-step zigzag stitching pattern changeover function)
LZ-2284NU-7 High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine with Anti-material-slip type (with standard/3-step zigzag stitching pattern changeover function and automatic thread trimmer)
Uneven feed of the upper and lower cloths is totally eliminated
With its newly developed feed mechanism, the machine prevents “uneven feed of the upper and lower cloths” when sewing girdles and body suits made of slippery, elastic materials.
Simplified mechanism for easy operation
Drop-feed sewing machines are widely said to feed in the lower cloth more quickly than the upper cloth. However, this machine prevents uneven feed of the upper and lower cloths in spite of its a drop-feed mechanism. In appearance, the gauge parts are identical to those of a conventional zigzag stitching machine, and operability is in no way affected by the newly developed feed mechanism.
With its newly developed feed mechanism, the machine prevents “uneven feed of the upper and lower cloths” when sewing girdles and body suits made of slippery, elastic materials.
Simplified mechanism for easy operation
Drop-feed sewing machines are widely said to feed in the lower cloth more quickly than the upper cloth. However, this machine prevents uneven feed of the upper and lower cloths in spite of its a drop-feed mechanism. In appearance, the gauge parts are identical to those of a conventional zigzag stitching machine, and operability is in no way affected by the newly developed feed mechanism.
Download files (1)
Apparel Sewing machines
LZ-2280N Series
High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
The cylinder bed zigzag stitch machine is best suited to the circular stitching processes of tubular products such as gridles, shorts and swimwear.
Feeding amount
2.2-2.5
mm
Sewing speed
4000-5000
sti/min
Product overview
The sewing machine produces soft seams with consistency with a low tension applied to the thread even when it runs at a high speed.
Highly reliable models in the LZ-2280N series that respond to many different kinds of sewing specifications.
LZ-2282N High speed, 1-needle, Lockstitch, Standard Zigzag Stitching machine with Lower Knife.
LZ-2282N-7 High speed, 1-needle, Lockstitch, Standard Zigzag Stitching Machine with Lower Knife (with automatic thread trimmer)
LZ-2284C-7 High speed, Cylinder-bed, 1-needle, Lockstitch, Standard Zigzag Stitching Machine with Automatic Thread Trimmer (with standard 3-step zigzag stitching pattern changeover function)
LZ-2285N High speed, 1-needle, Lockstitch Fagoting Machines.
LZ-2282N / LZ-2282N-7
Productivity is dramatically increased
The machine incorporates a built-in lower knife that trims only the lower material. This allows the machine to simultaneously attach lace to the body of the foundation and trim only the body during processes to attach lace to the bottoms or tops of slips or to the joint seam lines of shorts.
The machine demonstrates consistent trimming performance
The knife is driven by a motor that runs independently from the sewing machine motor. With this feature, the knife can continue to run at a high speeds during trimming even when the speed of the machine is reduced during startup or when sewing curved sections. Furthermore, the knife is placed just beside the needle to provide a constant trimming width even on the curved sections.
The machine incorporates a built-in lower knife that trims only the lower material. This allows the machine to simultaneously attach lace to the body of the foundation and trim only the body during processes to attach lace to the bottoms or tops of slips or to the joint seam lines of shorts.
The machine demonstrates consistent trimming performance
The knife is driven by a motor that runs independently from the sewing machine motor. With this feature, the knife can continue to run at a high speeds during trimming even when the speed of the machine is reduced during startup or when sewing curved sections. Furthermore, the knife is placed just beside the needle to provide a constant trimming width even on the curved sections.
LZ-2284C-7
This is a cylinder-bed, lockstitch zigzag stitching machine based on the LZ-2284N-7 model. The cylinder-bed more than adequately facilitates the handling of tubular sewing products in circular sewing processes, thereby contributing to increased productivity and upgraded seam quality. This zigzag stitching machine is best suited to the attaching or counter stitching of elastic tape.
LZ-2285N
The pressure provided by the left- and right-hand sections of the fagoting holder can be separately adjusted in order to prevent an uneven material feed.
The sewing machine provided with an anti-material-slip function, which promises more beautifully finished seams, is included in three different model lineups.
LZ-2280NU High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine with Anti-material-slip type
LZ-2284NU High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
with Anti-material-slip type
(with standard/3-step zigzag stitching pattern changeover function)
LZ-2284NU-7 High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine with Anti-material-slip type (with standard/3-step zigzag stitching pattern changeover function and automatic thread trimmer)
Uneven feed of the upper and lower cloths is totally eliminated
With its newly developed feed mechanism, the machine prevents “uneven feed of the upper and lower cloths” when sewing girdles and body suits made of slippery, elastic materials.
Simplified mechanism for easy operation
Drop-feed sewing machines are widely said to feed in the lower cloth more quickly than the upper cloth. However, this machine prevents uneven feed of the upper and lower cloths in spite of its a drop-feed mechanism. In appearance, the gauge parts are identical to those of a conventional zigzag stitching machine, and operability is in no way affected by the newly developed feed mechanism.
With its newly developed feed mechanism, the machine prevents “uneven feed of the upper and lower cloths” when sewing girdles and body suits made of slippery, elastic materials.
Simplified mechanism for easy operation
Drop-feed sewing machines are widely said to feed in the lower cloth more quickly than the upper cloth. However, this machine prevents uneven feed of the upper and lower cloths in spite of its a drop-feed mechanism. In appearance, the gauge parts are identical to those of a conventional zigzag stitching machine, and operability is in no way affected by the newly developed feed mechanism.
Specification
All Functions
Specification
Standard Accessories
